Features

Ultra-Rugged Construction

Available with epoxy-coated die-cast zinc or 316 stainless steel housing for superior corrosion resistance and heavy-duty durability

High-Grade Sealing

IP65/IP66/IP67 and NEMA 1, 3, 4, 4X, 6, 6P, 12, 13 rated, fully dust-tight, water-tight, oil-tight, and suitable for harsh washdown environments

Unique Ball-and-Socket Actuator

Secure head-body connection, stable actuation, and reduced wear for extended operational life

All-Metal Drive Train

Ensures consistent performance, high-temperature tolerance, and resistance to mechanical stress

Wide Temperature Range

Standard -40°C to +85°C; stainless steel version supports up to 121°C for high-heat applications

Extra-Long Service Life

Mechanical life up to 50 million cycles, perfect for high-frequency, continuous operation

Flexible Configuration

90° field-adjustable rotary actuator (CW/CCW compatible), multiple actuator options available

Reliable Contact System

SPDT/DPDT configurations with high-current silver alloy contacts for heavy-load switching

Easy Wiring & Installation

Self-lifting pressure plate terminals, 3/4 NPT conduit entries, standard heavy-duty mounting pattern

Superior Shock & Vibration Resistance

Built to withstand extreme mechanical stress in heavy machinery and rugged job sites

Global Certifications

 UL, CSA, CE approved for worldwide industrial deployment and compliance with international safety standards
