Features

1.Ultra‑compact design ideal for skid‑mounted systems and space‑constrained installations

2.Corrosion‑free glass‑reinforced plastic (GRP) enclosure with UV‑resistant polycarbonate cover

3.Tool‑free adjustable high‑resolution splined cams for precise switch setting

4.Integrated mounting legs and drive shaft conforming to NAMUR VDI/VDE 3845 standards

5.Flat visual position indicator (standard) or 3D position indicator (optional) for local status check

6.Single cable entry: M20×1.5 or 1/2" NPT with thickened thread for enhanced durability

7.Easy wiring via integrated PCB terminal block

8.Supports up to 2 SPDT/DPDT mechanical switches (silver‑ or gold‑plated), magnetic, or proximity sensors

8.NOVA V3™ switch option for high durability and power switching capacity

10.Optional AS‑Interface (ASI) communication module for digital networking

11.Protection rating: IP65, NEMA 4/4X

12.Operating temperature range: -15°C to +80°C (extended ranges available on request)

13.Suitable for indoor hazardous area applications with ATEX intrinsic safety certification
