Features

1.2‑wire loop‑powered design with HART® communication for seamless integration

2.Multi‑function: level transmitter, controller, and optional high/low level switches

3.Frictionless non‑contact sensor for high measurement stability and long service life

4.Smart digital filtering to minimize turbulence effects and ensure stable readings

5.Local pushbuttons and digital display for easy field setup and calibration

6.Compatible with ValVue, EDDL, DTM, and handheld communicators for remote configuration

7.Wide measurement range: 14″ to 120″ (355–3048 mm)

8.High‑pressure ratings: ANSI 150–2500; UNI‑DIN 10–100

9.Robust materials: carbon steel, stainless steel, chrome‑moly, Inconel torque tube options

10.SIL2 capable and certified for hazardous areas (ATEX, IECEx, FM, CSA)

11.IP66/IP67 weatherproof and dustproof enclosure

12.Supports liquid level, liquid‑liquid interface, and density measurement

13.Optional second 4–20 mA output for expanded system connectivity

Specifications

Range:

14” through 120” (355 through 3048 mm)

Ratings and connections:

flanged: ANSI 150 – 2500, UNI-DIN 10 - 100; screwed: NPT-F (1 1/2”, 2”); welded

Body materials:

carbon steel; stainless steel; chrome-moly

Displacer materials:

stainless steel; other materials on request

Torque Tube materials:

Inconel; stainless steel other materials on request
