Features

1.One-piece, thin profile, disc stem provides small obstruction to flow, resulting in high Cv, low pressure drops and good control characteristics.

2.Rounded polished disc edge gives full concentric sealing, lower torques, longer seat life and tight shut-off.

3.Triple function, resilient seat isolates body and stem from line media, provides drop-tight shut-off of line media at full-rated pressure and provides positive flange sealing, eliminating the need for flange gaskets.

4.Heavy duty, corrosion resistant top bushing provides upper stem support, absorbs actuator sideloading and extends valve cycle life.

5.Bi-directional, self-adjusting double V-cup stem seals prevent external contaminants from entering the valve.

6.Split body design enables easy field replacement of seat and disc/stem and permits direct mounting of Keystone actuators without the use of couplings or brackets.
