Features

1.Separate terminal enclosure is kept isolated from the electronics and motor compartment; only the wiring terminal is exposed during field installation

2.Standard adjustable torque switches, from 50 to 100% of rated torque output (3 steps: 50% - 75% - 100%)

3.Manual override is always engaged

4.Anodized aluminum with epoxy powder coat to protect unit against the decaying effects of aggressive environments

5.Visual mechanical position indicator for accurate visual reference of valve position

6.Directly mountable or readily adaptable to other quarter-turn valves

7.Permanently-lubricated, self-locking gear train helps eliminate the need for motor brakes; 8.picyclical gearing ensures reliable and smooth operation

9.Mechanical travel stops designed to prevent over-travel during hand wheel or motor operation

10.Over-temperature motor thermostat

11.Integral speed control, independently adjustable in opening and closing directions

12.Latched-type output contacts for fully open / fully closed remote indication. Output contacts for monitor and blinker/local selector indication are also available

13.Optional modules add even more functionality and intelligence:

OM1 – Modulating Input/Output module

OM3 – Local Interface module

OM9 – PROFIBUS DP V0/V1 bus communication

OM11 – DeviceNet bus communication

OM13 – 3-wire module

Specifications
