Baumann 85000 Sanitary Pinch Valve

Baumann 85000 sanitary pinch valves are intended for use with 3/4 inch O.D. pharmaceutical grade tubing. The 85000 is designed for use in both biotechnology and pharmaceutical industries, where cleanliness and sterility are required. The primary use is for disposable skid-based processes, replacing traditional manually operated valves. Automated valves offer consistent quality, better record keeping, and improved batch control.

Online consultation

Details

Features

1.Characterization of the Fisher FIELDVUE™ digital valve controller provides an installed equal percent flow characteristic for precision control.

2.The 85000 valve has no physical contact with the process fluid, due to the use of disposable tubing.

3.The tube shell design of the 85000 valve allows for easy change out of disposable tubing while providing stability during service.

4.Features a fail-close configuration.

5.Compact and light weight design reduces installed piping costs.

6.Epoxy powder-coated actuator with stainless steel fasteners for corrosion resistance.

Specifications

Critical Service	Low Flow, Sanitary
Material	Stainless
Operating Temperature	Standard Temperature, High Temperature
Process Connection Type	Flangeless/Inline
Control Type	On/Off, Positioning
Valve Size	NPS 3/4
Valve Size Standard	NPS
Other Configurations	Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product.
