Output Range

0-15 psig (0-1 bar), 0-30 psig (0-2 bar), 0-5 psig (0-0.4 bar)

Flow Capacity

Type 850: 24 scfm (679 Nl/min) at 100 psig (6.9 bar) supply, 60 psig (4.1 bar) output; Type 860 & 870: 2.2 gal/min

Exhaust Capacity

Type 850: 0.5 scfm (14 Nl/min) downstream pressure 10 psig (0.7 bar) above setpoint; Type 860 & 870: N/A

Maximum Supply Pressure

Type 850: 250 psig (17.2 bar); Type 860 & 870: 150 psig (10 bar)

Air Consumption

Type 850: Less than 6 scfh (3 Nl/min); Type 860 & 870: N/A

Operating Temperature

0° to +150°F (-18° to 60°C)

Weight

4.0 oz. (113 g)
