IMI Norgren B38-444-M2LA stainless steel filter/regulator 1/2 NPT
Designed for use in corrosive enviroments
Metallic parts meet NACE Standard MR-01-75
Lloyd’s register type approval
Applications include marine enviroments, oil and gas production, chemical and food processing, medical analysis
Relieving or non relieving models. Relieving models allow reduction of outlet pressure even when the system is dead-ended
| Medium | Compressed air |
|---|---|
| Operating Temperature | -40 ... 80 °C, -40 ... 175 °F |
| Standard | NACE MR-0175, 2002 revision |
| Port Size | 1/2 NPT |
| Drain Type | Manual |
| Gauge Port | 1/4 NPT |
| Filter Element | 25 μm |
| Adjustment | Adjusting screw |
| Maximum Inlet Pressure | 31 bar, 450 psi |
| Outlet Pressure Adjustment | 0.3 ... 9 bar, 4 ... 131 psi |
| Relieving/Non-Relieving | Relieving |
| Flow | 50 dm3/s, 106 scfm |
| Materials - Adjusting Knob | Stainless steel |
| Materials - Body | Stainless steel |
| Materials - Bonnet | Stainless steel |
| Materials - Bowl | Stainless steel |
| Materials - Elastomers | Synthetic rubber |
| Materials - Filter Element | Polyethylene (PE) |
| Country of Origin | China |
| Range | B38 |
| Brand | IMI Norgren |
Associated Products
B38P-254-B1MA
B38P-354-B1MA
B38P-254-A1MA
B38P-354-A1MA
B38P-444-A3KA
B38P-844-A3KA
B38P-844-A3MA
B38P-842-M1MA
B38P-254-M1MA
B38P-452-M3MA
B38P-442-M1MA
B38P-444-A3MG
B38P-444-M1KG
B38P-644-M2MA
B38P-244-A1MA
B38P-244-B1MA
B38P-344-A1MA
B38P-344-B1MA
B38P-354-B1MG
B38P-344-B3MA
B38P-244-A2MA
B38P-344-B2MA
B38P-244-B2MA
B38P-244-B3MA
B38P-244-A3MA
B38P-254-A2MA
B38P-254-A3MA
B38P-254-B2MA
B38P-354-B2MA
B38P-354-A2MA
B38P-354-A3MA
Pictures show
