IMI Norgren B38-242-B1MA stainless steel filter/regulator 5µm
Technical Details
Designed for use in corrosive enviroments
Metallic parts meet NACE Standard MR-01-75
Lloyd’s register type approval
Applications include marine enviroments, oil and gas production, chemical and food processing, medical analysis
Relieving or non relieving models. Relieving models allow reduction of outlet pressure even when the system is dead-ended
| Medium | Compressed air |
|---|---|
| Operating Temperature | -40 ... 80 °C, -40 ... 176 °F |
| Standard | NACE MR-0175, 2002 revision |
| Port Size | 1/4 NPT |
| Drain Type | Manual |
| Gauge Port | 1/4 NPT |
| Filter Element | 5 μm |
| Adjustment | Adjusting screw |
| Maximum Inlet Pressure | 31 bar, 450 psi |
| Outlet Pressure Adjustment | 0.4 ... 10 bar, 6 ... 145 psi |
| Relieving/Non-Relieving | Relieving |
| Flow | 8 dm3/s, 17 scfm |
| Materials - Adjusting Knob | Stainless steel |
| Materials - Body | Stainless steel |
| Materials - Bonnet | Stainless steel |
| Materials - Bowl | Stainless steel |
| Materials - Elastomers | Synthetic rubber |
| Materials - Filter Element | Stainless steel |
| Country of Origin | China |
| Range | B38 |
| Brand | IMI Norgren |
