Samson 45-9-DIN Self-operated regulators
Samson 45-9-DIN is a DIN-compliant self-operated flow regulator requiring no external power supply, designed to maintain a constant flow rate in fluid systems by closing automatically when the flow exceeds the preset value. It consists of a globe valve with adjustable restriction (orifice), an actuator with operating diaphragm, and a set point adjuster, controlling flow based on the differential pressure across the restriction and the set point spring tension.
Features
1.Flow regulator
2.Consisting of valve with integrated restriction and actuator
3.Single-seated valve with balanced plug
4.With connection nuts and welding or threaded ends
Specification
USAGE
Flow control
MEDIUM
Water and other liquids
Air and non-flammable gases
VERSION
DIN
MEDIUM TEMPERATURE
2 to 150 °C / 35.6 to 302 °F
VALVE SIZE
DN 15 to DN 50
PRESSURE RATING
PN 16 to PN 25
FUNCTION
Flow regulator
APPLICATION
Valve closes when the flow rate rises
FLOW RATE SET POINT
0.01 to 15 m³/h / 0.04 to 66 US gal/min
0.01 to 15 m³/h / 0.04 to 66 US gal/min
0.2 bar / 2.9 psi
