Features

• 1.316L Stainless Steel Construction: Exceptional corrosion resistance for harsh chemical, marine, and offshore environments, with wetted parts in stainless steel for extended service life

• 2.Diaphragm-Operated Design: Ensures bubble-tight shut-off even at low pressures, minimizing fluid loss and maximizing system efficiency

• 3.Ultra-Low Power Consumption: 3.5 W standard operation for energy savings in remote installations with limited power supply

• 4.Dual-Rated Explosion-Proof Certification: ATEX/IECEx II G Exd T6 (-50°C ≤ Ta ≤ +60°C) and T4 (-50°C ≤ Ta ≤ +80°C) as standard for Zones 1 & 2, Gas Groups IIA, IIB, IIC

• 5.1/4" NPT Porting: Standard 1/4" NPT female ports for easy integration with existing pipework and subplates

• 6.Broad Media Compatibility: Suitable for water, mineral oils, water glycols, methanol, and other non-corrosive fluids for versatile application flexibility

• 7.Ingress Protection: IP67 as standard (NEMA 6), with IP68 option available for third-party approval for submersible applications

• 8.Wide Temperature Range: Standard -50°C to +60°C, with high-temperature option (-20°C to +80°C) for extreme environments

• 9.Rapid Response Time: 10–15 ms actuation speed for precise flow control in dynamic hydraulic systems

• 10.Zero Pressure Rated: Operates reliably from 0 to maximum pressure without requiring minimum pressure differential

• 11.SIL Capable: Available with SIL2/SIL3 capability for safety-critical applications requiring third-party approval

• 12.Easy Maintenance: Dismountable without disturbing pipework for quick servicing and reduced downtime

•


Associated Products

Midland-ACS Associated Models

Regulators & Solenoid Valves – Cross Reference

1. Regulator Series (Pressure / Filter Regulators)

3500 Series – Standard Regulators

3500 Series: Pressure Regulators

3525 Series: Filter Regulators

3550 Series: Stainless Steel Filter Regulators (316L)

3575 Series: High Flow Filter Regulators

Typical Models:

4PRNSV082A

4FRASV122A

4REGSN121

4500 Series – Flow Regulators

4500 Series: Stainless Steel Flow Regulators

2REGSN122

2FRMSV122A

Other Pressure Control Units:

2PS3SV072

2PS3SL072

2. Solenoid Valve Series

67 Series – Direct Acting 3/2 Solenoid Valves

67 Series: 3/2 Direct Acting Solenoid Valves, 316L, Ex-proof

Typical Models:

DN03‑2221A41K6BA

DN03‑5322A41EBA

70 Series – High Pressure / High Temp Direct Acting Valves

70 Series: 3/2 Direct Acting Solenoid Valves (enhanced version)

1500 Series – Pilot Operated Solenoid Valves

1500 Series: 3/2, 5/2 Pilot Operated Valves, NACE, -50°C to +180°C

1500 Series with Solenoid Pilot

1600 / 1650 / 1750 Series – Pilot Operated Valves

1600 Series: Spring return pilot valves

1650 Series: With manual override

1750 Series: Double coil, high flow pilot valves

Explosion‑proof Solenoid Valves

5325M24‑AM1P4

5325M24PAM1P4

7325M24‑AM1P4

7325M24PAM1P4

8325M21‑SC2B

8325M21‑EC2B
