Features

• 1.316L Stainless Steel Construction: Exceptional corrosion resistance for harsh chemical, marine, and offshore environments, conforming to NACE MR-0175 for sour gas applications

• 2.Combined Filter-Regulator Design: Integrates filtration and pressure regulation in one compact unit for efficient air preparation

• 3.Large Flow Capacity: Optimized internal geometry for high flow rates, reducing pressure drop across the unit

• 4.Dual Filtration Options: 40 micron stainless steel element as standard, with 5 micron option available for applications requiring finer filtration

• 5.Flexible Drain Options: Manual drain as standard, with optional auto-drain for continuous operation in unmanned installations

• 6.Pressure Relief Options: Non-relieving or self-relieving configurations to meet specific system requirements

• 7.Wide Temperature Range: Standard: -20°C to +80°C (-4°F to +176°F); low temperature version available for -50°C to +80°C (-58°F to +176°F) operation

• 8.Transparent Bowl: Polycarbonate bowl with protective metal guard for visual inspection of filter element condition and condensate levels

• 9.Integral Mounting Holes: Facilitates easy installation and secure mounting in any orientation

• 10.Rolling Diaphragm: Ensures precise pressure control and consistent performance over the entire operating range

•


Associated Products

Midland-ACS Associated Models

Regulators & Solenoid Valves – Cross Reference

1. Regulator Series (Pressure / Filter Regulators)

3500 Series – Standard Regulators

3500 Series: Pressure Regulators

3525 Series: Filter Regulators

3550 Series: Stainless Steel Filter Regulators (316L)

3575 Series: High Flow Filter Regulators

Typical Models:

4PRNSV082A

4FRASV122A

4REGSN121

4500 Series – Flow Regulators

4500 Series: Stainless Steel Flow Regulators

2REGSN122

2FRMSV122A

Other Pressure Control Units:

2PS3SV072

2PS3SL072

2. Solenoid Valve Series

67 Series – Direct Acting 3/2 Solenoid Valves

67 Series: 3/2 Direct Acting Solenoid Valves, 316L, Ex-proof

Typical Models:

DN03‑2221A41K6BA

DN03‑5322A41EBA

70 Series – High Pressure / High Temp Direct Acting Valves

70 Series: 3/2 Direct Acting Solenoid Valves (enhanced version)

1500 Series – Pilot Operated Solenoid Valves

1500 Series: 3/2, 5/2 Pilot Operated Valves, NACE, -50°C to +180°C

1500 Series with Solenoid Pilot

1600 / 1650 / 1750 Series – Pilot Operated Valves

1600 Series: Spring return pilot valves

1650 Series: With manual override

1750 Series: Double coil, high flow pilot valves

Explosion‑proof Solenoid Valves

5325M24‑AM1P4

5325M24PAM1P4

7325M24‑AM1P4

7325M24PAM1P4

8325M21‑SC2B

8325M21‑EC2B
