Westlock AccuTrak Switchboxes 3300 Switchboxes Explosionproof/Flameproof
The Westlock AccuTrak 3300 Series is a new generation of intrinsically safe (Ex ia) valve position feedback switchboxes, designed for hazardous Zone 0/1/20/21 areas and serving as an upgraded replacement for the 2300 Series.
Features
1.Intrinsically Safe design meeting a wide range of worldwide approvals.
2.Inductive NAMUR sensor rated for IS applications.
3.Magnum switches with rhodium contacts for use with low power I/O’s for longer contact life.
4.Strong durable Beacon™ offers 360° visual indication available in a choice of styles and colors.
5.Touch set cams are hand adjustable, spring loaded and self-locking providing quick calibration of position switches and sensors.
6.Terminal strips are pre-wired and numbered with generous working space for ease of use.
7.Additional conduit for easy field wiring and mounting accessories as standard.
8.Wide range of switches and sensors.
9.Position transmitter option.
10.Switch stabilization plate.
11.Standardized mounting pattern for easy adaptation to common bracketry.
12.Range of drive shaft options.
13.Engineered resin enclosure is robust yet lightweight; allows broad operating temperatures and provides exceptional chemical, UV and impact resistance.
14.Aluminum enclosures with ultra-low copper content (0.2% maximum) ensure robust performance in corrosive environments.
15.Rugged stainless steel enclosure.
16.IP rated plugs certified where applicable.
Specifications
APPROVALS: | |
Area classification (ATEX/IEC) | |
2200/2300/2600/3300 Series: | Ex II *GD |
Ex ia II* T* G* | |
Ex tb IIIC T135°C Db IP6X | |
Enclosure standards (IEC) | |
All enclosures: | IP66/67 |
SWITCHES | |
All Models | V3 mechanical switches, SPDT, gold plated contacts |
Pepperl + Fuchs inductive NAMUR sensors | |
Magnum, SPDT (hermetically sealed proximity type) switches with rhodium contacts | |
ENCLOSURES | |
All Models | Engineered Resin |
Aluminium | |
Stainless steel |
Associated Products
AccuTrak 2000/2200 Series
2247ABYN00022AAA-AR1
2247ABYN00022ADZ-AR1
2249ABYN00042AAA-AR2
2249ABYN00042ADZ-AR2
2249SBYN00044ADZ-AR1
2004NBY2A2M0200
2004NBY2A2M02CSU
2007NBY2B2M0200
2007SBY4B2M0400U
AccuTrak 2600 Series
2645SBYN00022FAN-AR2
2645SBYN00022FAN-AR2
2645BYK00022FAN-00
2645BYCS22AD000
2646BYN00022ADZ-AR1
2647ABYN00022FAN-AR1
2647SBYN00022AAA-AR1
2647SBYN00022AAA-AR2
2649ABYN00022AAA-AR2
2649ABYN00022ADZ-AR2
2649ABYN00042ADZ-AR2
2649SBYN00022AAA-AR1
2649SBYN-CCJSV-01
Quantum 3000/3600 Series
3045RBYN000022AAA-AR1
3049SBYN00022AAA-AR1
3345RBYN0CS22FAN-AR1
3347ABYN00022ADZ-AR1
3347ABYN00022FAN-AR1
3347RBYN0CS22FAN-AR1
3347-S-BY-S-000-42FAN-AR1
3600NCMBY2M6XSO2600
Other Common Models
1040NBY2A2M0200
711NBY1A2M0900I2700U
811NBY2M9FIO5700UK
722A-BY-M9-FIO-4300-MO
316SB-STM-020-AAA
