Westlock AccuTrak Switchboxes 2300 Switchboxes Explosionproof/Flameproof
The Westlock AccuTrak 2300 series is an intrinsically safe (Ex ia) rotary valve position feedback switchbox designed specifically for hazardous areas. Primarily intended for high-risk operating conditions such as oil, chemical, and natural gas industries, it provides valve position signal feedback and visual status indication, serving as the intrinsically safe version of the 2200/2600 series.
Features
1.Intrinsically Safe design meeting a wide range of worldwide approvals.
2.Inductive NAMUR sensor rated for IS applications.
3.Magnum switches with rhodium contacts for use with low power I/O’s for longer contact life.
4.Strong durable Beacon™ offers 360° visual indication available in a choice of styles and colors.
5.Touch set cams are hand adjustable, spring loaded and self-locking providing quick calibration of position switches and sensors.
6.Terminal strips are pre-wired and numbered with generous working space for ease of use.
7.Additional conduit for easy field wiring and mounting accessories as standard.
8.Wide range of switches and sensors.
9.Position transmitter option.
10.Switch stabilization plate.
11.Standardized mounting pattern for easy adaptation to common bracketry.
12.Range of drive shaft options.
13.Aluminum enclosures with ultra-low copper content (0.2% maximum) ensure robust performance in corrosive environments.
14.Rugged stainless-steel enclosure.
15.IP rated plugs certified where applicable.
Specifications
TECHNICAL DATA - APPROVALS | Area classification (ATEX/IEC)2300 Series: Ex II* Ex ia II* T* G* Ex tb IIIC T135°C Db IP6X All enclosures IP66/67 |
SWITCHES | V3 mechanical switches, SPDT, gold plated contacts V3 inductive Namur proximity sensors Magnum, SPDT (hermetically sealed proximity type) Switches with rhodium contacts |
ENCLOSURES | AluminumStainless steel |
Associated Products
AccuTrak 2000/2200 Series
2247ABYN00022AAA-AR1
2247ABYN00022ADZ-AR1
2249ABYN00042AAA-AR2
2249ABYN00042ADZ-AR2
2249SBYN00044ADZ-AR1
2004NBY2A2M0200
2004NBY2A2M02CSU
2007NBY2B2M0200
2007SBY4B2M0400U
AccuTrak 2600 Series
2645SBYN00022FAN-AR2
2645SBYN00022FAN-AR2
2645BYK00022FAN-00
2645BYCS22AD000
2646BYN00022ADZ-AR1
2647ABYN00022FAN-AR1
2647SBYN00022AAA-AR1
2647SBYN00022AAA-AR2
2649ABYN00022AAA-AR2
2649ABYN00022ADZ-AR2
2649ABYN00042ADZ-AR2
2649SBYN00022AAA-AR1
2649SBYN-CCJSV-01
Quantum 3000/3600 Series
3045RBYN000022AAA-AR1
3049SBYN00022AAA-AR1
3345RBYN0CS22FAN-AR1
3347ABYN00022ADZ-AR1
3347ABYN00022FAN-AR1
3347RBYN0CS22FAN-AR1
3347-S-BY-S-000-42FAN-AR1
3600NCMBY2M6XSO2600
Other Common Models
1040NBY2A2M0200
711NBY1A2M0900I2700U
811NBY2M9FIO5700UK
722A-BY-M9-FIO-4300-MO
316SB-STM-020-AAA
