Fisher Y696VR Series Vacuum Regulators
Y696VR Series vacuum regulators are used where a decrease in vacuum must be limited, such as between a tank and vacuum source to control vacuum in a tank. A decrease in vacuum (increase in absolute pressure) on the diaphragm moves the disk away from the seat, allowing a higher vacuum source to return the system to the setpoint.
Features
1.Precision Control of Low-Pressure Settings
2.Corrosion Resistance
3.Installation Adaptability
4.Wide Material Selection
5.High Capacity
Specifications
Body Sizes and End Connection Styles | Cast Iron: 1-1/2 or 2 NPT Steel or Stainless Steel: NPS 1-1/2 or 2 / DN 40 or 50, NPT, SWE, CL150 RF, CL300 RF or PN 16/25/40 Hastelloy C: NPS 1-1/2 or 2 / DN 40 or 50, NPT or CL150 RF |
Maximum Control Pressure | Full Vacuum |
Maximum Downstream Pressure | Full Vacuum |
Vacuum Control Pressure Ranges | 1-inch w.c. to 3 psig / 2 mbar to 0.21 bar in six ranges |
Pressure Registration | Type Y696VR: Internal Type Y696VRM: External |
Temperature Capabilities | NBR: -40° to 180°F / -40° to 82°C FKM: 40° to 300°F / 4° to 149°C FFKM: 0° to 300°F / -18° to 149°C EPDM: -20° to 275°F / -29° to 135°C VMQ: -40° to 300°F / -40° to 149°C |
Approximate Weights | Cast Iron: 45 Pounds / 20 kg Steel, Stainless Steel, or Hastelloy C: 57 Pounds / 26 kg |
Additional Technical Data | For additional technical information, contact your local Sales Office or refer to technical documentation. |
