Fisher 646 Electro-Pneumatic Transducer
The Fisher 646 electro-pneumatic transducer uses a converter module that converts a 4 to 20 milliampere input signal to a proportional 0.2 to 1.0 bar (3 to 15 psig) pneumatic output signal. The converter module uses small parts of minimum mass, which are balanced symmetrically around a pivot point at the center of the mass. This balanced arrangement results in a high performance instrument that reduces sensitivity to vibration.
Features
The small size and light-weight design of the transducer facilitate mounting and provide improved space utilization.
The output volume of the transducer is adequate to drive valve/actuator combinations without requiring a positioner or volume booster.
The transducer has low air consumption, which lowers operating costs.
Modular design of the converter allows easy replacement in the field for reduced maintenance costs.
Specifications
Communication Protocol
4-20mA Analog
Data Interface
Wired
Diagnostics
No
Input Signal
Electric
Mounting Type
Remote Mount, Actuator Mount
Operating Temperature
Standard Temperature
Position Control
Modulating Control
